Function and Special Features
Jindex stepping plate cutting machine, can automatically feed action device. And operating software, can produce all the samples and samples, it can be used in clothing, shoes and bags and other industries, as well as compatible with all popular CAD systems. The high quality machine guarantees the extremely high accuracy and the speed, regardless of the cutting condition.
◇ Line drawing, drawing, text annotation, half knife cutting, full knife cutting, a complete. Meet the production target of less batch, more orders and more styles.
◇ The transmission system adopts imported linear guide rail, high speed, high precision, low sound, stable quality.
◇ Static board original imported parts from Japan, other parts and components also used a large number of imported products.
◇ The fastest cutting speed up to 1200mm/s.
◇ Standard I/O interface, in HP-GL format.
◇ Optional loading rack and automatic feeding device.
◇ Any CAD software can be connected, widely used in clothing, shoes, bags and handbags, laser knife mold drawing, lighting, advertising gifts, adhesive, color box packaging and other industries drawing and cutting.
| Flatbed Pen Cutter JD-A Series Technical Parameters Standard Table | |||
Technical Parameters/Model | JD-A-1209 | JD-A-1509 | JD-A-1512 |
Operating Characteristic | Computer operation and machine cutting can be performed simultaneously, as well data transmission can be completed quickly and used continuously. | ||
Cutting Speed | Up to 1200mm/s | ||
Cutting Thickness | ≤2.0 MM | ||
Cutting Material | Yellow thick cardboard, red cardboard, PVC board, white cardboard, chicken paper, fiber midsole and plastic board,etc. | ||
Cutting Method | Multi-purpose knife holder, 4 sets of different strokes, half-knife, full-knife settings | ||
Pen Type/Knife Type | Ordinary signature pen, oil pen, ball pen / Special steel knife | ||
Fixed Way | Double-sided adhesive paste / vacuum adsorption / electrostatic adsorption | ||
Mechanical Resolution | 0.005 mm | ||
Software Resolution | 0. 025mm、0. 01mm、0. 1mm optional | ||
Cutting Circular Diameter | ≧2mm diameter | ||
Transmission Interface | Standard parallel port, serial port | ||
Format Compatible | AI software, Autocad, Coreldraw and all box design software can be directly output without conversion, with automatic optimization | ||
Command System | HP-GL&GP-GL | ||
CNC Panel | Liquid crystal display and contact buttons | ||
Transmission Material | Linear guide, imported synchronous belt | ||
Voltage and Power | AC 220V ± 10%, 50HZ; Fuse Size 6A | ||
Cutting Area | 1200mm*900mm | 1500mm*900mm | 1500mm*1200mm |
Appearance Size | 1580x1330x920mm | 1850x1330x920mm | 1850x1610x920mm |
Imported timing belt ensures safe and stable transmission
Synchronous gear accessories
Knife pen double head design automatic cutting conversion
Imported balanced linear guides ensure uninterrupted cutting and precise cutting profiles
User-friendly control panel
Connect to other CAD systems by importing HPGL format files
